EX-30E / MC-11
Exam Equipment Base Cabinet
Shown is a BPA configurable planning concept informed by clinical workflow research. Specifications can be customized to project needs.
Configuration: Custom sizing or validated dimensions
Final dimensions and details are coordinated to the approved project requirements.
Configure this moduleFinal dimensions and details are coordinated to the approved project requirements.
CONFIGURABLE PLANNING ENVELOPE24–36 W × 22–30 D × 28–36 H in
Standard planning envelope: 24–36 W × 22–30 D × 28–36 H in. Final dimensions follow approved shop drawings.
APPLICATIONSExam room · Diagnostic room
Workflow position: Below-counter equipment zone · Care delivery wall
CORE MODULE STRUCTURE
- Ventilation-ready planning bay
- Removable service access
PROJECT-CONFIGURED OPTIONS
- Door/open bay
- Cable grommets
- Pull-out equipment shelf
Project-Configured
Select listed options and coordinate dimensions through approved shop drawings.
Fully Custom
Develop a room-specific cabinet package when standard modules do not resolve the workflow.
PLANNING FEATURES
- Planned ventilation-ready planning bay
- Planned removable service access
- Configuration may be adapted to the approved room plan
VERIFY BEFORE RELEASE
- Named equipment
- Heat/ventilation
- Power/data and load
